ACM Grooving Router Bit
Designed for folding and shaping Aluminium Composite Cladding Materials such as Alucobond, Dibond etc. Routing 90/100/108Ā° V-shaped grooves into the aluminium cover and part of the polyethylene core, allows folding the remaining material by hand to a 90/100/108Ā° angle.
Dimensions:
Diameter (D) =Ā 18mm
D1Ā = 3mm
DĀ attach (S) = 8mm
A = 90Ā°
Dimensions:
Diameter (D) =Ā 14mm
DĀ attach (S) =Ā 12mm
A = 108Ā°
100Ā° Diamond Tipped ACM Grooving Router Bit. *Extreme service life*
For bending ACM panels 90 degrees.
Suitable for ACM panels with mineral core.
Dimensions:
Diameter (D) =Ā 14mm
DĀ attach (S) =Ā 12mm
A = 100Ā°
